1.69 Inch TFT LCD Display





Item	1.69 inch TFT LCD display
Resolution	240*280
Outline Size	30.07*37.48*1.64mm
Active Area	27.97*32.63mm
Operating Voltage	2.8 V
Controller	ST7789V2
Viewing direction	12 o'clock
Interface	SPI
Display Technology	TFT
Operating Temperature	-20 to 70ºC
Storage Temperature	-30 to 80ºC





Model NO.	HL17H1
LCD Drive Mode	Static Drive LCD Module
Customized	Non-Customized
Viewing Angle	12 O′clock
Backlight	White LED *3
Surface Treatment	Anti-Glare
Color Arrangement	RGB-Stripe
Connector	FPC
Transport Package	Carton/Pallet
Size	1.69 inch
Origin	China
HS Code	9013803010
Production Capacity	1000000 PC/Year





* High brightness LED backlight

* Transmissive LCD is compact in size with a low 3.0 voltage power supply

* 4-wire resistive touch panel

* Enhances communication efficiency

* Smooth operation

* Accurate rendering of images and graphics





* RoHS compliant

* Adhere to strict environmental and safety standards

* Low 3.0 voltage power supply

* Impressive display quality





* Communication equipment

* Office automation

* Industrial applications

* Smart applications

* Automobiles





Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples of different item numbers are acceptable.



Q2. What about the lead time?

A: For off-shelf products, in-stock samples immediately. 1-2 weeks for sample remaking. 4-6 weeks for mass production. For design-in products, 3-5 days for counter drawing proposal; 2 weeks for sample making at drawing approval; 5-6 weeks for trial-run/mass production at sample approval.



Q3. Do you have any MOQ limit for sample and production order?

A: Low MOQ. 3-5pcs for sample checking is available. Mass production MOQ is normally 1K/lot. We support qty lower than MP MOQ for trail-run/PP-run order.



Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 5-7 days to arrive. Airline and sea shipping also optional.



Q5. How to proceed an order for LCD module?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.



Q6. Is it OK to print my logo on the LCD product?

A: Yes. Please inform us formally in design stage, and we will make samples with your logo for your sample test and approval. At sample approval, the mass production will follow the approved samples.



Q7: Do you offer guarantee for the products?

A: Yes, we offer 1 year warranty to our products.



Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, during the guarantee period, we will send new lcds with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.





HAILI MICROELECTRONICS TECHNOLOGY CO.,LTD is a leading OEM/ODM LCD display, LCD moudles and back lights manufacture in Chen Zhou, HuNan, Founded in 2004 has been specializing in designing, developing, manufacturing LCD display, TFT LCD display, LCD moudle, backlights and LED display for over 19 years and is an ISO9001, ISO14001, IATF16949 certified and SGS-audited factory.

HAILI occupies an area of 20, 000 square meters, With over 400 professionally trained workers, and equipped with auto modern facilities, HLW has a remarkable production capacity of 800, 000-1, 000, 000 groups /yearly. 60 skilled technicians in R&D dept, can make 420 new styles monthly and have invented more than 45 patents.

HAILI mainly produces thousands of types of standard or customized TN, HTN, STN, FSTN, DFSTN, VA, COG, COB, TFT and other LCD screens, digital tubes and backlights. Products can be widely used in instrumentation, office equipments, industrial control, household appliances, weighing apparatus, telecommunications, medical treatment, military industry, bank display terminals, navigation and aerospace, automobiles central control, etc.

Ever since its foundation, HLW has been implementing strict quality control policies to ensure the quality of every single delivery. We insists on keeping in strict accordance with AQL 0.25 inspection.

HAILI group have three factories that are located in Chen Zhou and Shen Zhen. The new factory will establish a brand-new automatic LCD production line, module line and other related production lines to meet the needs of the customer market.



Production Lines: Full automatic and clean production line with strict management
